SERI PENGGILINGAN UJUNG
55103913 ~ 55103938
Keterangan
Spesifikasi
4 ALUR GAGANG PANJANG UJUNG PERSEGI
SATUAN: mm
| NOMOR BARANG | TIPE NO. | DIAMETER (D1) |
SERULING PANJANG (L2) |
OAL (L1) |
BETIS SLIDE (d2) |
|---|---|---|---|---|---|
| 55103913 | SINYAL 0104 | 1.0 | 3 | 75 | 4 |
| 55103914 | SINYAL 0104A | 1.0 | 3 | 100 | 6 |
| 55103915 | SINYAL 0154 | 1.5 | 4.5 | 75 | 4 |
| 55103916 | SINYAL 0154A | 1.5 | 4.5 | 100 | 6 |
| 55103917 | SINYAL 0204 | 2.0 | 6 | 75 | 4 |
| 55103918 | SINYAL 0204A | 2.0 | 6 | 100 | 6 |
| 55103919 | SINYAL 0304 | 3.0 | 8 | 75 | 4 |
| 55103920 | SINYAL 0304A | 3.0 | 8 | 100 | 6 |
| 55103921 | SINYAL 0404 | 4.0 | 10 | 75 | 4 |
| 55103922 | SINYAL 0404A | 4.0 | 10 | 100 | 6 |
| 55103923 | SINYAL 0504 | 5.0 | 13 | 75 | 6 |
| 55103924 | SINYAL 0504A | 5.0 | 13 | 100 | 6 |
| 55103925 | SINYAL 0604 | 6.0 | 15 | 75 | 6 |
| 55103926 | SINYAL 0604A | 6.0 | 15 | 100 | 6 |
| 55103927 | SINYAL 0604B | 6.0 | 15 | 150 | 6 |
| 55103928 | SINYAL 0804 | 8.0 | 20 | 75 | 8 |
| 55103929 | SINYAL 0804A | 8.0 | 20 | 100 | 8 |
| 55103930 | SINYAL 0804B | 8.0 | 20 | 150 | 8 |
| 55103931 | SINYAL 1004 | 10.0 | 30 | 100 | 10 |
| 55103932 | SINYAL 1004A | 10.0 | 30 | 150 | 10 |
| 55103933 | SINYAL 1204 | 12.0 | 30 | 100 | 12 |
| 55103934 | SINYAL 1204A | 12.0 | 30 | 150 | 12 |
| 55103935 | SINYAL 1604 | 16.0 | 40 | 150 | 16 |
| 55103936 | SINYAL 1604A | 16.0 | 40 | 200 | 16 |
| 55103937 | SINYAL 2004 | 20.0 | 40 | 150 | 20 |
| 55103938 | SINYAL 2004A | 20.0 | 40 | 200 | 20 |
KONDISI PEMOTONGAN YANG DIREKOMENDASIKAN UNTUK MILL UJUNG PERSEGI
| BAHAN KEKERASAN |
BAJA KARBON. BAJA PADUAN S45C, FC, FCD, SCM, S50C, SKS… ~HRC30 |
BAJA PADUAN. BAJA PERKAKAS. SCR, SNCM, SKD11, SKD61, NAK80… ~HRC50 |
BAJA KERAS SKD11 ~HRC60 |
|||
|---|---|---|---|---|---|---|
| DIAMETER (mm) |
KECEPATAN (mm-1) |
MEMBERI MAKAN mm/menit |
KECEPATAN (mm-1) |
MEMBERI MAKAN mm/menit |
KECEPATAN (mm-1) |
MEMBERI MAKAN mm/menit |
| 1 | 20000 | 80 | 15000 | 45 | 11000 | 30 |
| 1.5 | 13600 | 135 | 10000 | 60 | 9000 | 40 |
| 2 | 9600 | 150 | 8500 | 50 | 6000 | 45 |
| 3 | 6500 | 200 | 5800 | 75 | 4000 | 60 |
| 4 | 5500 | 250 | 4000 | 80 | 3200 | 60 |
| 5 | 4500 | 300 | 3000 | 80 | 2500 | 70 |
| 6 | 4000 | 300 | 2500 | 80 | 2200 | 70 |
| 8 | 3500 | 350 | 2200 | 90 | tahun 1700 | 70 |
| 10 | 3000 | 400 | Tahun 2000 | 90 | 1500 | 70 |
| 12 | 2500 | 400 | 1500 | 100 | 1000 | 70 |
| 16 | Tahun 2000 | 400 | 1200 | 100 | 800 | 70 |
