KEPALA BOR SPINDEL GANDA UNTUK KAYU
54101141, 54101142, 54101143, 54101144, 54101145
Keterangan
Spesifikasi
▼ KEPALA BOR 3-SPINDEL (LINEAR) (UNTUK KAYU)
- Jarak antar spindel dapat disesuaikan: 14-200 mm.
SATUAN: mm
| NOMOR BARANG | MODEL | UKURAN | JARAK | POROS JENIS |
|||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | G | H | L1 | L | X | Y | MENIT | MAKS | KAPASITAS MAKSIMUM | |||
| 54101141 | 3C-W14 | 10 | 10 | 28 | 55 | 121 | 58 | 3 | 18 | 107 | 132 | 40 | 73,8 | 14 | 88 | Ø10 | M8×1.25, M10×1.5 |
| 54101142 | 3C-W20 | 0 | 10 | 28 | 55 | 150 | 71 | 3 | 17 | 112 | 137 | 46 | 88,8 | 20 | 112 | Ø15 | M8×1.25, M10×1.5 |
| 54101143 | 3C-W22 | 0 | 10 | 28 | 55 | 162 | 76 | 3 | 17 | 114 | 139 | 46 | 88,8 | 22 | 128 | Ø20 | M8×1.25, M10×1.5 |
| 54101144 | 3C-W26 | 0 | 10 | 28 | 55 | 191 | 92 | 3 | 15 | 118,5 | 143,5 | 46 | 88,8 | 26 | 152 | Ø30 | M8×1.25, M10×1.5 |
| 54101145 | 3C-W36 | 0 | 10 | 28 | 72 | 251 | 114 | 3 | 15 | 141 | 166 | 70.7 | 70.7 | 36 | 200 | Ø50 | M8×1.25, M10×1.5 |
