ROLLS FOR KNURLING BY DEFORMATION
55105053, 55105054, 55105055, 55105056, 55105057, 55105058, 55105059, 55105060, 55105061, 55105062, 55105063, 55105064, 55105065, 55105066, 55105067, 55105068, 55105069, 55105070
Description
Specification
TYPE: RDAA
SPIRAL ANGLE β=0°
HSS/TIN
UNIT: mm
| ITEM NO. | MODEL | PITCH | DIMENSIONS | ADAPTABLE HOLDERS | ||
|---|---|---|---|---|---|---|
| T | D | W | d | |||
| 55105053 | RDAA-150404-0004 | 0.4 | 15 | 4 | 4 | 55105110 (PRCSR-1244) or 55105111 (PRCSR-1644) |
| 55105054 | RDAA-150404-0005 | 0.5 | ||||
| 55105055 | RDAA-150404-0006 | 0.6 | ||||
| 55105056 | RDAA-150404-0007 | 0.7 | ||||
| 55105057 | RDAA-150404-0008 | 0.8 | ||||
| 55105058 | RDAA-150404-0010 | 1.0 | ||||
| 55105059 | RDAA-150404-0012 | 1.2 | ||||
| 55105060 | RDAA-150404-0015 | 1.5 | ||||
| 55105061 | RDAA-200806-0004 | 0.4 | 20 | 8 | 6 | 55105114 (PRCSR-2086) or 55105115 (PRCSR-2586) |
| 55105062 | RDAA-200806-0005 | 0.5 | ||||
| 55105063 | RDAA-200806-0006 | 0.6 | ||||
| 55105064 | RDAA-200806-0007 | 0.7 | ||||
| 55105065 | RDAA-200806-0008 | 0.8 | ||||
| 55105066 | RDAA-200806-0010 | 1.0 | ||||
| 55105067 | RDAA-200806-0012 | 1.2 | ||||
| 55105068 | RDAA-200806-0015 | 1.5 | ||||
| 55105069 | RDAA-200806-00175 | 1.75 | ||||
| 55105070 | RDAA-200806-0020 | 2.0 | ||||
