ROLLS FOR KNURLING BY DEFORMATION (CONVEX SERIES)
55105127, 55105128, 55105129, 55105130, 55105131, 55105132, 55105133, 55105134, 55105135, 55105136, 55105137, 55105138, 55105139, 55105140, 55105141, 55105142, 55105143, 55105144
Description
Specification
TYPE: MRLV SPIRAL ANGLE β=30°
TYPE: MRRV SPIRAL ANGLE β=30°
*MRLV & MRRV sold as a set.
UNIT: mm
| ITEM NO. | MODEL | ITEM NO. | MODEL | PITCH | DIMENSIONS | ADAPTABLE HOLDERS | ||
|---|---|---|---|---|---|---|---|---|
| T | D | W | d | |||||
| 55105127 | MRLV-200606-3004 + | 55105136 | MRRV-200606-3004 | 0.4 | 20 | 6 | 6 | 51105116 (PSHMR-2066) or 51105117 (PSHMR-2566) |
| 55105128 | MRLV-200606-3005 + | 55105137 | MRRV-200606-3005 | 0.5 | ||||
| 55105129 | MRLV-200606-3006 + | 55105138 | MRRV-200606-3006 | 0.6 | ||||
| 55105130 | MRLV-200606-3008 + | 55105139 | MRRV-200606-3008 | 0.8 | ||||
| 55105131 | MRLV-200606-3010 + | 55105140 | MRRV-200606-3010 | 1.0 | ||||
| 55105132 | MRLV-200606-3012 + | 55105141 | MRRV-200606-3012 | 1.2 | ||||
| 55105133 | MRLV-200606-3015 + | 55105142 | MRRV-200606-3015 | 1.5 | ||||
| 55105134 | MRLV-200606-3016 + | 55105143 | MRRV-200606-3016 | 1.6 | ||||
| 55105135 | MRLV-200606-3020 + | 55105144 | MRRV-200606-3020 | 2.0 | ||||
