KNURLING ROLL HOLDERS FOR KNURLING BY DEFORMATION
55105109, 55105110, 55105111, 55105112, 55105113, 55105114, 55105115
Description
Specification
- TYPE: PRCSR
USE RDAA. RDGV KNURLING ROLL
UNIT: mm
| ITEM NO. | MODEL | DIMENSIONS | ROLLS SPEC. | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| H x B | L | C | E | G | K | |||||
| 55105109 | PRCSR-1044 | 10 x 10 | 100 | 10 | 15 | 2 | 4 | 15 | 4 | 4 |
| 55105110 | PRCSR-1244 | 12 x 12 | 120 | 12 | 15 | 2 | 4 | 15 | 4 | 4 |
| 55105111 | PRCSR-1644 | 16 x 16 | 120 | 16 | 15 | 2 | 4 | 15 | 4 | 4 |
| 55105112 | PRCSR-2066 | 20 x 20 | 100 | 20 | 22 | 3 | 5 | 20 | 6 | 6 |
| 55105113 | PRCSR-2566 | 25 x 25 | 130 | 25 | 25 | 3 | 5 | 20 | 6 | 6 |
| 55105114 | PRCSR-2086 | 20 x 20 | 120 | 20 | 20 | 2 | 5 | 20 | 8 | 6 |
| 55105115 | PRCSR-2586 | 25 x 25 | 130 | 25 | 23 | 2 | 5 | 20 | 8 | 6 |
