KNURLING ROLL HOLDERS FOR KNURLING BY CUTTING
55105018, 55105019, 55105020, 55105021
Description
Specification
UNIT: mm
| ITEM NO. | MODEL | DIMENSIONS | RANGE OF PROCESSING |
ROLLS SPEC. | |||||
|---|---|---|---|---|---|---|---|---|---|
| H x B | L | F | E | ||||||
| 55105018 | PRZSR-1236-K | 12 x 12 | 110 | 24 | 19 | 3-40 | 11 | 3 | 6 |
| 55105019 | PRZSR-1636-K | 16 x 16 | 110 | 24 | 19 | 4-60 | 11 | 3 | 6 |
| 55105020 | PRZSR-20511 | 20 x 20 | 130 | 36 | 30 | 6-100 | 20 | 5 | 11 |
| 55105021 | PRZSR-25511 | 25 x 25 | 150 | 41 | 35 | 6-250 | 25 | 5 | 11 |
