CNC ROTARY TABLES
52172054, 52172055, 52172056, 52172057
Description
Specification
| ITEM NO. | UNIT | 52172054 | 52172055 | 52172056 | 52172057 | |
|---|---|---|---|---|---|---|
| Work table diameter | mm | ø125 | ø170 | ø210 | ø255 | |
| Center bore diameter | mm | ø30H7 | ø40H7 | ø40H7 | ø40H7 | |
| Through-hole diameter | mm | ø25 | ø40 | ø40 | ø40 | |
| Height of table (horizontal) | mm | 155 | 158 | 158 | 186 | |
| Height of center (vertical) | mm | 110 | 135 | 160 | 160 | |
| Width of T-slot | mm | 12H7 | 12H7 | 12H7 | 12H7 | |
| Width of guide block | mm | 14 | 18 | 18 | 18 | |
| Drive pressure / method | kgs/cm2 | 5/ Pneumatic | 5/ Pneumatic | 5/ Pneumatic | 5/ Pneumatic | |
| Clamping torque | kgs.m | 8 | 18 | 26 | 26 | |
| Servo motor type | Fanuc | α2i | α4i | α4i | α4i | |
| Mitsubishi | HF74T/ 44T | HF53T | HF53T | HF53T | ||
| Transmission ratio | 1/90 | 1/90 | 1/90 | 1/90 | ||
| Max. table speed | min-1 | 44.4 | 44.4 | 44.4 | 44.4 | |
| Allowable loading inertia | kgs.cm.s2 | 2 | 5.5 | 8.4 | 8.4 | |
| Resolution | deg. | 0.001 | 0.001 | 0.001 | 0.001 | |
| Indexing accuracy | sec. | 40 | 20 | 20 | 20 | |
| Repeatability | sec. | 4 | 4 | 4 | 4 | |
| Net weight (servo motor excluded) | kgs | 25 | 52 | 57 | 58 | |
| Allowable loading capacity | Vertical | kgs | 50 | 75 | 75 | 75 |
| Horizontal | kgs | 100 | 150 | 150 | 150 | |
| Tailstock applied | kgs | 100 | 150 | 150 | 150 | |
| Clamping torque | Axial | kgs | 970 | 1400 | 1400 | 1400 |
| Radial x length | kgs.m | 41 | 102 | 102 | 102 | |
| Radial x radius | kgs.m | 8 | 18 | 26 | 26 | |
| Allowable cutting torque | kgs.m | 8.5 | 17 | 25 | 25 | |
