AIR POWER DRAWBAR
52150053
Description
Specification
FRL unit with control valve
- Pneumatic power drawbar.
- Easy to install, operate & maintain.
- MAX. TORQUE: 279ft-lbs (379n-m)
- R.P.M.: 700
FEATURES:
- Fits for spindle taper of R8, NT30, NT40, NT50
- Automate your present milling machine by installing our air power drawbar.
- 10 minutes easy installation: No special drawbar, tool, toolholder & collets require, use the existing drawbar.
- Unique adjustable drawbar feature enable the operator to preset length of power drawbar.
- It comes with complete socket set of 6 sizes: #17, #19, #21, #22, #23, #26 m/m for universal use and easy installation.
- The universal mounting base require NO drilling and NO tapping on the vari-able speed milling machine.
- This unit is pneumatic powered by normal shop air supply of 90 P.S.I.
- Tool changing by operating the control button.
- To ensure long lasting life the air unit motor are made from NICKEL CHROME TUNGSTEN ALLOY STEEL with latest technology in mechanical design for heavy duty industrial grade use.
- The air filter, oil lubricator, control valve & all air fiting are all made from good quality material, to reduce the change resulted from breaking down.
