Schaftfräser
55101595, 55101596, 55101597, 55101598, 55101599, 55101600
Beschreibung
Spezifikation
F90SE09 Empfohlene Einsätze: KYOCERA
EINHEIT: mm
| ARTIKEL-NR. | MODELL | EINFÜGEN | ABMESSUNGEN | SCHRAUBEN | SCHLÜSSEL | ||||
|---|---|---|---|---|---|---|---|---|---|
| D | H | D | d (Zoll) | Ich Nein | |||||
| 55101595 | F90SE09-D40A04R | SEMM09T3PESR | 40 | 40 | 16 | - | 4 | CS30070 | DBIT-T10 |
| 55101596 | F90SE09-D50A05R | 50 | 46 | 22 | - | 5 | |||
| 55101597 | F90SE09-D63A05R | 63 | 46 | 22 | 1" | 5 | |||
| 55101598 | F90SE09-D80B06R | 80 | 50 | 27 | 1" | 6 | |||
| 55101599 | F90SE09-D100B08R | 100 | 50 | 32 | 1-1/4" | 8 | |||
| 55101600 | F90SE09-D125B10R | 125 | 55 | 40 | 1-1/2" | 10 | |||
